The Yale YR11KCFRUS26D has been discontinued
** See similar or replacement items below **
Item # bci4121805
Yale YH Series Passage Door Lever Set with Kincaid Lever
Model: YR11KCFRUS26D|Item: bci4121805
from theYH Series Collection
Discontinued
We still have product details and accessories, scroll down to see them!
Discontinued
We still have product details and accessories, scroll down to see them!
Details
Features:
- ANSI/BHMA certified grade 2
- Constructed of high quality materials for lasting durability
- Reversible handing for left or right handed doors
- Installs easily and includes mounting hardware
- Round corner latch faceplate included
- ADA compliant lever
- Concealed screws for a sleek look
- Covered by a limited lifetime warranty
Specifications:
- Backset: Adjustable 2-3/8" or 2-3/4"
- Cross Bore: 2-1/8"
- Edge Bore: 1"
- Door Thickness: 1-1/2", 1-3/4", 1-3/8", 1-5/8"
- Handle Length: 4-1/2"
- Handle Projection: 2-7/16"
- Trim Width: 2-9/16"
Dimensions and Measurements
Backset | Adjustable 2-3/8" or 2-3/4" |
Cross Bore | 2-1/8" |
Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
Edge Bore | 1" |
Handle Length | 4.5 in. |
Handle Projection | 2.4375 in. |
Product Weight | 0.5 lbs. |
Trim Height | 2.5625 in. |
Trim Width | 2.5625 in. |
Dimensions and Measurements
Backset | Adjustable 2-3/8" or 2-3/4" |
Cross Bore | 2-1/8" |
Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
Edge Bore | 1" |
Handle Length | 4.5 in. |
Handle Projection | 2.4375 in. |
Product Weight | 0.5 lbs. |
Trim Height | 2.5625 in. |
Trim Width | 2.5625 in. |
Characteristics and Features
Concealed Screws | Yes |
Function | Passage |
Handing | Left, Reversible, Right |
Latch Faceplate | Round Corner |
Lever Shape | Straight |
Material | Zinc |
Rosette Shape | Round |
Theme | Transitional |
Characteristics and Features
Concealed Screws | Yes |
Function | Passage |
Handing | Left, Reversible, Right |
Latch Faceplate | Round Corner |
Lever Shape | Straight |
Material | Zinc |
Rosette Shape | Round |
Theme | Transitional |
Warranty and Product Information
ADA | Yes |
ANSI Certification | A156.2 |
Approved for Commercial Use | No |
BHMA Certification | Grade 2 |
Certifications | ANSI |
Collection | YH Series |
Country Of Origin | China |
Fire Rated | No |
Manufacturer Warranty | Limited Lifetime |
Warranty and Product Information
ADA | Yes |
ANSI Certification | A156.2 |
Approved for Commercial Use | No |
BHMA Certification | Grade 2 |
Certifications | ANSI |
Collection | YH Series |
Country Of Origin | China |
Fire Rated | No |
Manufacturer Warranty | Limited Lifetime |
Reviews
(3)
2.3 out of 5 Stars
