The Kwikset 155MILRDT-514 has been discontinued
** See similar or replacement items below **
Item # bci2901694
Kwikset Milan Privacy Door Lever Set with Push Button Lock and Emergency Egress
Model: 155MILRDT-514|Item: bci2901694
from theMilan Collection
Discontinued
We still have product details and accessories, scroll down to see them!
Discontinued
We still have product details and accessories, scroll down to see them!
Details
Features:
- Interior Rosette has Exposed Screws and are not Concealed on the Interior Side
- Solid Zinc Construction
- ANSI / BHMA Grade 2 Certified
- Self Aligning Post Feature Makes Installation Easy
- Handing is Easily Reversed
- Push Button Locking
- Emergency Egress Function
- Strengthened Springs Ensure that the Lever Stays Level Over Time
- Flush Head Mounting Screws
- Includes Square Corner, Round Corner and Drive-In Faceplates
- Square Corner and Round Corner Faceplates Measure 1" x 2-1/4"
- Includes Round Corner Strike
- Kwikset's Lifetime Mechanical and Lifetime Finish Warranty
Specifications:
- Backset: Adjustable to 2-3/8" or 2-3/4"
- Cross Bore: 2-1/8"
- Edge Bore: 1"
- Door Thickness: 1-3/8" or 1-3/4"
- Handing: Reversible
- Lever Length: 4-5/32"
- Projection: 2-9/32"
Featured Technologies:
- Privacy Function: The latch bolt can be locked by pushing the button on the inside lever. An emergency release tool can unlock the door from the outside. This function is ideal for bathroom or bedroom doors where privacy is desired but a keyed cylinder isn't necessary.
- Emergency Egress Function: Allows you to simply turn the lever to exit the room, without having to stop to unlock it.
Dimensions and Measurements
Backset | 2-3/4", Adjustable 2-3/8" or 2-3/4", 2-3/8" |
Cross Bore | 2-1/8" |
Door Thickness | 1-3/4", 1-3/8" |
Edge Bore | 1" |
Handle Length | 4.1562 in. |
Handle Projection | 2.5625 in. |
Trim Height | 2.625 in. |
Trim Width | 2.625 in. |
Dimensions and Measurements
Backset | 2-3/4", Adjustable 2-3/8" or 2-3/4", 2-3/8" |
Cross Bore | 2-1/8" |
Door Thickness | 1-3/4", 1-3/8" |
Edge Bore | 1" |
Handle Length | 4.1562 in. |
Handle Projection | 2.5625 in. |
Trim Height | 2.625 in. |
Trim Width | 2.625 in. |
Characteristics and Features
Concealed Screws | No |
Function | Privacy |
Handing | Left, Reversible, Right |
Handle Material | Metal |
Latch Faceplate | Round Corner |
Lever Shape | Round, Straight |
Locking Mechanism | Trim Lock |
Rosette Shape | Round |
Style | Modern |
Theme | Modern |
Characteristics and Features
Concealed Screws | No |
Function | Privacy |
Handing | Left, Reversible, Right |
Handle Material | Metal |
Latch Faceplate | Round Corner |
Lever Shape | Round, Straight |
Locking Mechanism | Trim Lock |
Rosette Shape | Round |
Style | Modern |
Theme | Modern |
Warranty and Product Information
ADA | Yes |
ANSI Certification | A156.2 |
Approved for Commercial Use | No |
BHMA Certification | Grade 2 |
Certifications | ANSI |
Collection | Milan |
Manufacturer Warranty | Limited Lifetime Mechanical |
Series | Signature Series, Contemporary |
Warranty and Product Information
ADA | Yes |
ANSI Certification | A156.2 |
Approved for Commercial Use | No |
BHMA Certification | Grade 2 |
Certifications | ANSI |
Collection | Milan |
Manufacturer Warranty | Limited Lifetime Mechanical |
Series | Signature Series, Contemporary |
