Generac 50-Amp 240V Single-Phase Select Circuit Transfer System with 10-Circuit Load Center (Aluminum)

Features:

Generac 50-A HomeLink™ Upgradeable Manual Transfer Switch
• Meets your needs today and when you're ready to upgrade
Pre-Wired 50-Amp Manual Transfer Switch
• Interchangeable breakers make it easy to reconfigure or expand
Also Includes
• (1) 10' 50-Amp (CS6364) and NEMA 14-50P Power Cord
• (1) 50-Amp (CS6364) Aluminum Power Inlet Box (must be hardwired)
Safely Power Hard-Wired Circuits
• The electricity you need to power your furnace, sump pumps, etc.
From Manual to Automatic - Essential Circuit Coverage
• From a portable to a standby generator (11kW Max)
Ready When You Are (By Cert Electrician)
• Field-upgradable to an automatic switch panel and new faceplate
Includes 10 Total Circuits (Expands up to 16)
• (1) 30-Amp 2-Pole and (1) 20-Amp 2-Pole
• (2) 20-Amp 1-Pole and (2) 20-Amp 1-Pole Tandem
Versatile Design and Flexible and Cost Effective Installation
• Can be used with GFCI and Non-GFCI portable generators
• Uses 1" standard, tandem, GFCI and AFCI breakers
*Requires 50-Amp 2-Pole Breaker in Main Load Center (Not Included)
5-Year Limited Warranty

Overview:

• Transfer Switch Style: Select Circuit
• Product Weight: 33 lbs
• Depth: 4"
• Width: 15-13/16"
• Height: 15-3/8"

Specifications:

• Voltage: 240V
• Frequency: 60 Hz
• Electrical Phases: 1
• Max Generator Input: 50A
• Enclosure Material: NEMA 1R

Product Assurance:

• Certifications: UL
• Warranty: 5 Year
