Item # bci2071585
The Ellington Fans E-ROU54CH5LKRW has been discontinued
** See similar or replacement items below **
Item # bci2071585
Ellington Fans Modern 54" 5 Blade Indoor Ceiling Fan - Light Kit Included
Model: E-ROU54CH5LKRW|Item: bci2071585
Discontinued
We still have product details and accessories, scroll down to see them!
Discontinued
We still have product details and accessories, scroll down to see them!
Details
Included Components:
- 8" Downrod
- Light Kit
Features:
- Dry Location rated
- Wall Control means you'll always know where the fan control is
Blade Specifications:
- Blade Span: 54"
- Number of Blades: 5
- Blade Pitch: 14°
Motor Specifications:
- Motor Size: 188mm x 22mm
- CFM (Cubic Feet per Minute), High: 6252
- Voltage: 120 V
- Number of Speeds: 3
Sloped Ceiling Specifications:
- For ceilings with slope from 35° to 45°, use the 45AD angled ceiling adapter
High or Low Ceiling Specifications:
- The Rousseau is designed for installation on standard 8 to 9 foot ceilings. If your ceiling is higher, you'll need to purchase an additional downrod. The rule of thumb is that ceiling fans should have a minimum of 7 feet and a maximum of 9 feet of clearance between the bottom of the fan and the floor in order to circulate air efficiently. If you have a low ceiling, purchase the CMA flush mount adapter to reduce the hanging height of your fan.
Suggested Downrod Lengths:
- 9 Foot Ceiling: 6" - 12"
- 10 Foot Ceiling: 12" - 18"
- 11 Foot Ceiling: 18" - 24"
- 12 Foot Ceiling: 24" - 36"
- 13 Foot Ceiling: 36" - 48"
- 14 Foot Ceiling: 48" - 60"
- 15 Foot Ceiling: 60" - 72"
- For ceiling heights greater than 15 feet, you'll need to purchase the downrod Coupler to join two downrods together.
Manufacturer Resources
Installation GuideDimensions and Measurements
Blade Pitch | 14 Degrees |
Blade Span | 54 in. |
CFM (High) | 6252 |
Downrod Size(s) | 8 in. |
Height | 22 in. |
Motor Size | 188 mm |
Dimensions and Measurements
Blade Pitch | 14 Degrees |
Blade Span | 54 in. |
CFM (High) | 6252 |
Downrod Size(s) | 8 in. |
Height | 22 in. |
Motor Size | 188 mm |
Included Components
Downrod(s) Included | Yes |
Light Kit Included | Yes |
Included Components
Downrod(s) Included | Yes |
Light Kit Included | Yes |
Characteristics and Features
Blade Finish | Dark Wood |
Bulb Base | GU24 |
Bulb Type | Halogen |
Control Type | Wall, Remote |
Light Direction | Down Lighting |
Light Kit Compatible | Yes |
Number of Blades | 5 |
Number of Bulbs | 1 |
Style | Retro |
Theme | Art Deco |
Characteristics and Features
Blade Finish | Dark Wood |
Bulb Base | GU24 |
Bulb Type | Halogen |
Control Type | Wall, Remote |
Light Direction | Down Lighting |
Light Kit Compatible | Yes |
Number of Blades | 5 |
Number of Bulbs | 1 |
Style | Retro |
Theme | Art Deco |
Electrical and Operational Information
Speeds | 3 |
Wattage | 24 |
Watts Per Bulb | 24 |
Electrical and Operational Information
Speeds | 3 |
Wattage | 24 |
Watts Per Bulb | 24 |
Warranty and Product Information
Certifications | UL |
Collection | Modern |
Energy Star | No |
Location Rating | Dry Location |
Warranty and Product Information
Certifications | UL |
Collection | Modern |
Energy Star | No |
Location Rating | Dry Location |
