Broan Fresh In™ 180 CFM Full Install Energy Star Certified Supply Fan with Washable Aluminum Filter and Insulated Housing Inserts
Model: FIN-180P|Item: bci4621093
from theFresh In Collection
Details
Ultra compact, Broan Fresh In™ supply fans can be installed easily between 12” ceiling joists with the included bracket, and between 16” and 24” joists with a separate mounting bracket kit (Model Number FIN-S1624, not included). Fresh In supply fans mount flush to the ceiling, in the attic, in a wall, or anywhere it fits and can be properly ducted. With an optional finishing ring and a paintable filter access door, the ventilator blends in wherever it is installed.
All models are available either hardwired or with a 6-ft power cord
Features:
- Broan Fresh In means code compliance or comfort mode settings, constant airflow and easy maintenance
- For any typical installation, the built-in intelligence delivers airflow without losing efficiency, filter clogging, or ducting situations that affect static pressure
- Molded foam and insulated housing inserts protect against air leakage and condensation
- Washable aluminum filter with optional MERV 8 (mold spore and fine dust capture) and MERV 13 (mold spore, fine dust, bacteria and smoke capture) filters
- Recognized as the most efficient of Energy Star® in 2022
- This model is sold with a 6-ft power cord
Specifications:
- CFM: 180
- Duct Size: 6" Round
- Grille Width: 10.25"
- Grille Length: 14.75"
- Width: 10-1/4"
- Depth: 10-1/4"
- Amperage: 0.7A
- Voltage: 120V
- Wattage: 13.4W, 40W
Dimensions and Measurements
CFM | 180 |
Depth | 10.25 in. |
Duct Size | 6" Round |
Grille Length | 14.75 in. |
Grille Width | 10.25 in. |
Length | 14.75 in. |
Product Weight | 11 lbs. |
Width | 10.25 in. |
Dimensions and Measurements
CFM | 180 |
Depth | 10.25 in. |
Duct Size | 6" Round |
Grille Length | 14.75 in. |
Grille Width | 10.25 in. |
Length | 14.75 in. |
Product Weight | 11 lbs. |
Width | 10.25 in. |
Included Components
Heater Included | No |
Includes Remote | No |
Light Included | No |
Motion Sensor | No |
Included Components
Heater Included | No |
Includes Remote | No |
Light Included | No |
Motion Sensor | No |
Characteristics and Features
Duct Discharge | Horizontal |
Fan Type | Attic Fan |
Housing Shape | Rectangle |
Humidity Sensing | No |
Installation Type | Fan Only |
Material | Metal |
Mount Type | Ceiling |
Characteristics and Features
Duct Discharge | Horizontal |
Fan Type | Attic Fan |
Housing Shape | Rectangle |
Humidity Sensing | No |
Installation Type | Fan Only |
Material | Metal |
Mount Type | Ceiling |
Electrical and Operational Information
Amperage | 0.7 |
Drive Type | Direct Drive |
Power Source | Plug-In |
Sones | 0 |
Speeds | 2 |
Voltage | 120 |
Wattage | 13.4, 40 |
Electrical and Operational Information
Amperage | 0.7 |
Drive Type | Direct Drive |
Power Source | Plug-In |
Sones | 0 |
Speeds | 2 |
Voltage | 120 |
Wattage | 13.4, 40 |
Warranty and Product Information
ADA | No |
Approved for Commercial Use | No |
Certifications | HVI |
Collection | Fresh In™ |
Country Of Origin | Mexico, USA |
Energy Star | Yes |
Fire Rated | No |
Made in America | Yes |
Manufacturer Warranty | 5 Year Parts |
Warranty and Product Information
ADA | No |
Approved for Commercial Use | No |
Certifications | HVI |
Collection | Fresh In™ |
Country Of Origin | Mexico, USA |
Energy Star | Yes |
Fire Rated | No |
Made in America | Yes |
Manufacturer Warranty | 5 Year Parts |
