The Zurn Z880-BLUE has been discontinued

** See similar or replacement items below **

Zurn
Alternate View
Item # bci1543917

Zurn 3" High Density Polyethylene Trench Drain Approved for Pedestrian Traffic up to 1,000 lbs. NO SLOPE and SHALLOW Throat (Price Per 4ft Section)

Model: Z880-BLUE
|
Item: bci1543917

Discontinued

We still have product details and accessories, scroll down to see them!

Discontinued

We still have product details and accessories, scroll down to see them!

Details

3" High Density Polyethylene Trench Drain Approved for Pedestrian Traffic up to 1,000 lbs. NO SLOPE and SHALLOW Throat (Price Per 4ft Section)

Ordering Information:

Using quantity to designate number of 4-foot sections, first specify the total length of your system.  As an example, choosing Qty: 3 signifies a 12-foot system.  Next choose the grate that you would like supplied.  Once satisfied with these selections, click "add to cart."  Before reaching the cart we will prompt you with the available outlets and end caps to complete the system.  Please note that because online shopping carts do not recognize multiple systems, if you are ordering two or more distinct trench systems (for multiple areas of your property), a phone order will be required.

Zurn Flo-Thru® Trench Drains:

Zurn Flo-Thru® trench drain systems are designed for ease of installation, load-bearing stregth, chemical resistance, and structural integrity. Strong and durable, Zurn trench drains are appropriate for not only residential sidewalks, driveways, and swimming pools, but also manufacturing facilities, parking lots, sports arena''s, and roads.  Zurn Flo-Thru® systems offer several advantages over either on-site forming or precast polymer concrete systems.  Lightweight modular assemblies reduce labor and installation time, eliminate costly leveling/alignment hardware and reduce costly freight charges.  Built-in molded slope produces superior flow characteristics. Smooth, non-porous internal surface further enhances flow. Modular sections are assembled together to produce straight, uniform drainage systems.

Product Features:

  • No Slope.  Intended for shorter runs (or runs w/ several outlets) and less flow demand.
  • Shallow throat for depth-restricted applications
  • Very narrow width appropriate for residential applications including pools and landscaping
  • Approved to 1,000 lbs (Pedestrian foot-traffic only)
  • Highly corrosion resistant high density polyethylene channels
  • Smooth interior with 0% water absorbtion
  • 3" Width, 1-3/4" throat width
  • Variety of grating options
  • Integral rebar clips to accomodate vertical rebar
  • Mechanical overlap connection with interlocking ends
  • End outlets and bottom outlets are available in 1-1/2" sizing
  • Made in the USA

Manufacturer Resources

Specification Sheet

Dimensions and Measurements

Depth
3.5 in.
Length
12 in.
Width
4.75 in.

Dimensions and Measurements

Depth
3.5 in.
Length
12 in.
Width
4.75 in.

Warranty and Product Information

Approved for Commercial Use
Yes

Warranty and Product Information

Approved for Commercial Use
Yes
