Zephyr Tornado I 200 - 600 CFM 28 Inch Wide Insert Range Hood with LumiLight LED Lighting

Model: AK8100BS
|
Item: bci4255351

$749.00
Finish: Stainless Steel -
236 In Stock
    Free Shipping!
    Leaves the Warehouse in 1 to 2 business days
    -
    Return & Shipping Details

    Details

    The Tornado I provides muscle and flexibility in a small, barely-visible packaged beneath your custom hood enclosure. This 600-CFM insert is upgraded with two hybrid baffle filters, dual-level LumiLight LED lighting, and an angled housing for a better fit within any custom hood. An optional adjustable-depth, stainless steel liner is available to protect your cabinetry and provide a more finished appearance.

    Features:

    • Blower outputs up to 600 CFM to keep your kitchen free of cooking fumes and odors
    • Hybrid baffle filters utilize stainless steel baffles for an improved aesthetic and aluminum mesh for efficient filtration
    • 3 speed mechanical slide controls allow you to easily set the power level of your range hood
    • Dual-Level LumiLight LED lighting illuminates cooking area
    • Optional liner accessories available
    • Covered under a 1 year labor and 10 year parts warranty

    Product Technologies:

    • LumiLight LED Lighting: LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours. The multi-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
    • Optional Ductless Recirculating Kit: Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen

    Specifications:

    • CFM: 200, 600
    • Sones: 1.4, 6
    • Nominal Width: 28"
    • Width: 27-9/16"
    • Height: 10-1/2"
    • Depth: 11-3/16"
    • Duct Size: 6" Round
    • Ceiling Height: 96" - 144"
    • Amperage: 3A
    • Voltage: 120V
    • Wattage: 360W
    Additional Zephyr Links

    Dimensions and Measurements

    Ceiling Height (Max)
    144 in.
    Ceiling Height (Min)
    96 in.
    CFM
    200, 600
    Depth
    11.19 in.
    Duct Size
    6" Round
    Height
    10.5 in.
    Height Above Cooktop
    20" to 34"
    Nominal Width
    28 in.
    Product Weight
    21.6 lbs.
    Width
    27.5625 in.

    Dimensions and Measurements

    Ceiling Height (Max)
    144 in.
    Ceiling Height (Min)
    96 in.
    CFM
    200, 600
    Depth
    11.19 in.
    Duct Size
    6" Round
    Height
    10.5 in.
    Height Above Cooktop
    20" to 34"
    Nominal Width
    28 in.
    Product Weight
    21.6 lbs.
    Width
    27.5625 in.

    Included Components

    Available Without Blower
    No
    Bulb Included
    Yes
    Convertible to Ductless / Recirculating
    Yes
    Ductless
    Yes
    Includes Remote
    No
    Light Included
    Yes

    Included Components

    Available Without Blower
    No
    Bulb Included
    Yes
    Convertible to Ductless / Recirculating
    Yes
    Ductless
    Yes
    Includes Remote
    No
    Light Included
    Yes

    Characteristics and Features

    Blower Type
    Internal
    Bulb Type
    LED
    Control Type
    Slide
    Duct Discharge
    Horizontal, Vertical
    Filter Type
    Baffle Filters
    Installation Type
    Full Installation
    Material
    Stainless Steel
    Number of Bulbs
    2
    Panel Ready
    No
    Smart Home
    No

    Characteristics and Features

    Blower Type
    Internal
    Bulb Type
    LED
    Control Type
    Slide
    Duct Discharge
    Horizontal, Vertical
    Filter Type
    Baffle Filters
    Installation Type
    Full Installation
    Material
    Stainless Steel
    Number of Bulbs
    2
    Panel Ready
    No
    Smart Home
    No

    Electrical and Operational Information

    Amperage
    3
    Sones
    1.4, 6
    Speeds
    3
    Voltage
    120
    Wattage
    360
    Watts Per Bulb
    6

    Electrical and Operational Information

    Amperage
    3
    Sones
    1.4, 6
    Speeds
    3
    Voltage
    120
    Wattage
    360
    Watts Per Bulb
    6

    Warranty and Product Information

    ADA
    No
    Approved for Commercial Use
    No
    Collection
    Core Collection
    Country Of Origin
    Taiwan
    Energy Star
    No
    Manufacturer Warranty
    1 Year Labor, 10 Year Parts
    Outdoor Approved
    No
    Title 24
    Yes

    Warranty and Product Information

    ADA
    No
    Approved for Commercial Use
    No
    Collection
    Core Collection
    Country Of Origin
    Taiwan
    Energy Star
    No
    Manufacturer Warranty
    1 Year Labor, 10 Year Parts
    Outdoor Approved
    No
    Title 24
    Yes
