Schlage
Antique Brass

Schlage One Sided Deadbolt with Interior Blank Plate

Model: B661P609
|
Item: bci490358

$365.65
Finish: Antique Brass -
Special Order
Finish: Antique Brass -
Special Order
placeholder
Free Shipping!
Leaves the Warehouse in 3 to 7 weeks
-
Return & Shipping Details

Details

One-Sided Deadbolt from the B600 Series

The deadbolt is thrown or retracted by a turn unit only with no outside trim. The bolt automatically deadlocks when it is fully thrown.

  • Single cylinder outside, blank plate inside
  • Deadbolt: 1 1/8" x 2 1/4", Square corner faceplate, 1" housing diameter, 1" throw
  • Strike: 1 1/8" x 2 3/4", Square corner box
  • Cylinder: 6-pin solid brass, keyed 6-pin, C123 keyway
  • Door Range: 1 5/8" - 2"
Additional Schlage Links

Manufacturer Resources

Specification Sheet

Dimensions and Measurements

Backset
2-3/4", 2-3/8"
Cross Bore
2-1/8"
Door Thickness
1-1/2", 1-3/4", 1-3/8", 1-5/8", 1-7/8", 2", 2-1/2", 2-1/4", 2-1/8", 2-3/8"
Edge Bore
1"

Dimensions and Measurements

Backset
2-3/4", 2-3/8"
Cross Bore
2-1/8"
Door Thickness
1-1/2", 1-3/4", 1-3/8", 1-5/8", 1-7/8", 2", 2-1/2", 2-1/4", 2-1/8", 2-3/8"
Edge Bore
1"

Included Components

Interchangeable Core
No

Included Components

Interchangeable Core
No

Characteristics and Features

Concealed Screws
No
Cylinder
6 Pin Schlage C
Cylinder Type
Single Cylinder
Function
Deadbolt, Interior Deadbolt
Keyway
C123
Latch Faceplate
Square Corner
Mortise
No
Theme
Traditional

Characteristics and Features

Concealed Screws
No
Cylinder
6 Pin Schlage C
Cylinder Type
Single Cylinder
Function
Deadbolt, Interior Deadbolt
Keyway
C123
Latch Faceplate
Square Corner
Mortise
No
Theme
Traditional

Warranty and Product Information

ADA
No
ANSI Certification
A156.5
Approved for Commercial Use
Yes
BHMA Certification
Grade 1
Certifications
UL
Collection
B600, B600 Series
Fire Rated
Yes
Manufacturer Warranty
3 Year Limited
Series
B600-Series

Warranty and Product Information

ADA
No
ANSI Certification
A156.5
Approved for Commercial Use
Yes
BHMA Certification
Grade 1
Certifications
UL
Collection
B600, B600 Series
Fire Rated
Yes
Manufacturer Warranty
3 Year Limited
Series
B600-Series
