Metalbest 8" Inner Diameter - Ultra-Temp Class A Chimney Pipe - Double Wall - 12" Pipe Length
Model: 208012U|Item: bci1070058
from the8 Inch Ultra-Temp Collection
$179.48
Finish: Stainless Steel -
3 In Stock
Details
8" x 12" Class A Chimney Pipe Length from Ultra-Temp
Pipe lengths provide the core part of the chimney system. Pipes should match the inside diameter of all other pieces and all pieces should be from the same manufacturer.
Ultra-Temp is designed for all-fuel applications and comes with 430 stainless steel outer casing. Ultra-Temp chimney pipe is insulated with 1" solid pack and UL Listed to UL-103 HT standards. These parts feature an advanced engineering design, offering 300 Series stainless steel inner pipe and 1-inch Mineral Wool Fibre insulation.
Features:
- Materials: Stainless steel
- Clearance: 2" to combustibles
- Allowable Flue Gas Temperatures:
- Maximum Continuous: 1,000 Degrees Fahrenheit / 540 Degrees Celsius
- Brief Forced Firing: 1,400 Degrees Fahrenheit / 760 Degrees Celsius (60 min.)
- Creosote Burn Out: 2,100 Degrees Fahrenheit / 1,150 Degrees Celsius (3 x 10 min.)
Manufacturer Resources
Installation GuideDimensions and Measurements
Length | 12 in. |
Outside Diameter | 10 in. |
Pipe Inside Diameter | 8 in. |
Pipe Length | 12 in. |
Dimensions and Measurements
Length | 12 in. |
Outside Diameter | 10 in. |
Pipe Inside Diameter | 8 in. |
Pipe Length | 12 in. |
Characteristics and Features
Configuration | Pipe Length |
Material | Stainless Steel |
Pipe Class | Class A |
Pipe Shape | Round |
Vent Construction | Double Wall |
Characteristics and Features
Configuration | Pipe Length |
Material | Stainless Steel |
Pipe Class | Class A |
Pipe Shape | Round |
Vent Construction | Double Wall |
Electrical and Operational Information
Fuel Type | Coal, Oil, Wood |
Electrical and Operational Information
Fuel Type | Coal, Oil, Wood |
Warranty and Product Information
Approved for Commercial Use | No |
Certifications | UL |
Collection | Ultra-Temp |
Manufacturer Warranty | Limited Lifetime |
Warranty and Product Information
Approved for Commercial Use | No |
Certifications | UL |
Collection | Ultra-Temp |
Manufacturer Warranty | Limited Lifetime |
