Grundfos TP 4040/4 UGZ BUBE Single Stage Centrifugal Inline Single Head Pump with a Rated Head of 10.2 Ft, a Shaft Seal of BUBE and Bronze Construction
Model: G91122124|Item: bci1688280
Details
TP 4040/4 UGZ BUBE Single Stage Centrifugal Inline Single Head Pump with a Rated Head of 10.2 Ft, a Shaft Seal of BUBE and Bronze Construction
TP 4040/4 UGZ BUBE Single stage centrifugal inline single head pump. The inline design with opposite suction and dis charge ports enables mounting in pipe work or on a concrete foundation. The shaft seal is a corrosion resistant maintenance free mechanical seal.
Technical:
- Rated flow: 44 US gpm
- Rated head: 10.2 ft
- Shaft seal: BUBE
- Maximum operating pressure: 145 psi
Material:
- Pump housing: Bronze
- Pump housing: DIN W.-Nr. 2.1093
- Impeller: Stainless steel
- Impeller: DIN W.-Nr. 1.4301
- Impeller: AISI 304
Installation:
- Maximum operating pressure: 145 psi
- Flange standard: USA
- Pipe connection: 1 1/2"
Liquid:
- Liquid temperature range: 5 .. 284 °F
Electrical Data:
- Number of poles: 4
- Power (P2) required by pump: 0.335 HP
Dimensions and Measurements
Depth | 6.375 in. |
Product Weight | 44.8 lbs. |
Width | 13.5 in. |
Dimensions and Measurements
Depth | 6.375 in. |
Product Weight | 44.8 lbs. |
Width | 13.5 in. |
Characteristics and Features
Material | Bronze |
Characteristics and Features
Material | Bronze |
