Grundfos 625S7504A Multistage Submersible Pump with a Rated Flow of 625 US GPM, a Rated Head of 374 Ft and Stainless Steel Construction
Model: G17BG00A4|Item: bci1687813
Details
625S7504A Multistage Submersible Pump with a Rated Flow of 625 US GPM, a Rated Head of 374 Ft and Stainless Steel Construction
625S7504A Multistage submersible pump for raw water supply, groundwater lowering and pressure boosting. The pump is suitable for pumping clean, thin, non-aggressive liquids without solid particles or fibers. The pump is made entirely of Stainless steel DIN W.Nr. DIN W.Nr. 1.4301 and suitable for horizontal and vertical installation. The pump is fitted with a built-in non-return valve.
Technical:
- Speed for pump data: 3450 rpm
- Rated flow: 625 US gpm
- Rated head: 374 ft
- Curve tolerance: ISO9906
Material:
- Pump: Stainless steel
- Pump: DIN W.-Nr. 1.4301
- Pump: AISI 304
- Impeller: Stainless steel
- Impeller: DIN W.-Nr. 1.4301
- Impeller: AISI 304
Installation:
- Pump outlet: 6" NPT
- Motor diameter: 8" inch
- Minimum borehole diameter: 10" mm
Electrical Data:
- Power (P2) required by pump: 75 HP
Manufacturer Resources
Specification SheetDimensions and Measurements
Height | 44.063 in. |
Product Weight | 116 lbs. |
Width | 8.625 in. |
Dimensions and Measurements
Height | 44.063 in. |
Product Weight | 116 lbs. |
Width | 8.625 in. |
Characteristics and Features
Material | Stainless Steel |
Characteristics and Features
Material | Stainless Steel |
