Grundfos 230S40012 Multistage Submersible Pump with a Rated Flow of 229 US GPM, a Rated Head of 509 Ft and Stainless Steel Construction

Model: G15B70012
|
Item: bci1687702

$8,255.00
Special Order
placeholder
Free Shipping!
Leaves the Warehouse in 6 to 10 weeks
-
Return & Shipping Details

Details

230S40012 Multistage Submersible Pump with a Rated Flow of 229 US GPM, a Rated Head of 509 Ft and Stainless Steel Construction

230S40012 Multistage submersible pump for raw water supply, groundwater lowering and pressure boosting. The pump is suitable for pumping clean, thin, non-aggressive liquids without solid particles or fibers. The pump is made entirely of Stainless steel DIN W.Nr. DIN W.Nr. 1.4301 and suitable for horizontal and vertical installation. The pump is fitted with a built-in non-return valve.

Technical:

  • Speed for pump data: 3450 rpm
  • Rated flow: 229 US gpm
  • Rated head: 509 ft
  • Curve tolerance: ISO9906

Material:

  • Pump: Stainless steel
  • Pump: DIN W.-Nr. 1.4301
  • Pump: AISI 304
  • Impeller: Stainless steel
  • Impeller: DIN W.-Nr. 1.4301
  • Impeller: AISI 304

Installation:

  • Pump outlet: 3" NPT
  • Motor diameter: 6 inch
  • Minimum borehole diameter: 6" mm

Liquid:

  • Maximum liquid temperature: 104 °F

Electrical Data:

  • Power (P2) required by pump: 40.2 HP
  • Start. method: direct-on-line
Additional Grundfos Links

Manufacturer Resources

Specification Sheet

Dimensions and Measurements

Height
64 in.
Product Weight
71.8 lbs.
Width
5.75 in.

Dimensions and Measurements

Height
64 in.
Product Weight
71.8 lbs.
Width
5.75 in.

Characteristics and Features

Material
Stainless Steel

Characteristics and Features

Material
Stainless Steel
