Grundfos 16S2018 Multistage Submersible Pump with a Rated Flow of 17.6 US GPM, a Rated Head of 367 Ft and Stainless Steel Construction
Model: G10010018|Item: bci1687378
Details
16S2018 Multistage Submersible Pump with a Rated Flow of 17.6 US GPM, a Rated Head of 367 Ft and Stainless Steel Construction
16S2018 Multistage submersible pump for raw water supply, groundwater lowering and pressure boosting. The pump is suitable for pumping clean, thin, non-aggressive liquids without solid particles or fibers. The pump is made entirely of Stainless steel DIN W.Nr. DIN W.Nr. 1.4301 and suitable for horizontal and vertical installation. The pump is fitted with a built-in non-return valve.
Technical:
- Speed for pump data: 3450 rpm
- Rated flow: 17.6 US gpm
- Rated head: 367 ft
Material:
- Pump: Stainless steel
- Pump: DIN W.-Nr. 1.4301
- Pump: AISI 304
- Impeller: Stainless steel
- Impeller: DIN W.-Nr. 1.4301
- Impeller: AISI 304
Installation:
- Pump outlet: 1 1/4" NPT
- Motor diameter: 4 inch
Liquid:
- Maximum liquid temperature: 104 °F
Electrical Data:
- Power (P2) required by pump: 2.61 HP
- Start. method: direct-on-line
Manufacturer Resources
Specification SheetDimensions and Measurements
Height | 21 in. |
Product Weight | 12.5 lbs. |
Width | 4 in. |
Dimensions and Measurements
Height | 21 in. |
Product Weight | 12.5 lbs. |
Width | 4 in. |
Characteristics and Features
Material | Stainless Steel |
Characteristics and Features
Material | Stainless Steel |
