Delta Commercial Single Handle Laboratory Faucet
Model: W6600-9-C|Item: bci2243001
from theCommercial Collection
$184.75
Finish: Chrome -
Special Order
Details
Product Features:
- All brass body with vandal resistant locking pin to prevent damage to counter top(can be removed in field if not required)
- Assembled shank
- Brass locknut and raised lockwasher to provide positive gripping during installation
- Teck Lab compression structure
- Chrome plated brass renewable seat
- 1/4" NPT tailpiece and coupling nut
- Spout can be oriented to suit left, center, or right side handle operation
- Deckmount single faucet with rigid/swivel spout, fits a maximum 1-1/4" diameter hole
- Spout: R5 - Gooseneck-6.0" radius-12.0" height(unmounted)-Standard rigid/swivel field installation unless LS Limited swing option selected-Vandal resistant .090" wall thickness
- Outlet#: 9 - w/ 1/4" ID Serrated Nozzle Outlet Plus In-Line Dual Check Vacuum Breaker(-9 series)
- Handle#: C - 70 mm (2-3/4") ADA compliant Lever Blade Handle-Metal-Color indexed-Vandal resistant screws
- Indexed For: CW - Cold Water(Green)-60 psi max
Product Certifications:
- CSA certified
- Complies to ASME A112.18.1/CSA B125.1
- ADA compliant and meets Handicapped Accessibility Standard ASME A117.1 of less than 5 lbs
- In-line VB tested and approved in conformance with ASSE 1035 “Laboratory Faucet Vacuum Breakers”. CSA certified to B64.7
Dimensions and Measurements
Height | 14.74 in. |
Max Deck Thickness | 1.5 in. |
Product Weight | 6.22 lbs. |
Spout Height | 6.04 in. |
Spout Reach | 6 in. |
Spout Swivel | 360 Degrees |
Dimensions and Measurements
Height | 14.74 in. |
Max Deck Thickness | 1.5 in. |
Product Weight | 6.22 lbs. |
Spout Height | 6.04 in. |
Spout Reach | 6 in. |
Spout Swivel | 360 Degrees |
Included Components
Drain Assembly Included | No |
Escutcheon Included | No |
Filtering | No |
Handles Included | Yes |
Sidespray | No |
Valve Included | Yes |
Included Components
Drain Assembly Included | No |
Escutcheon Included | No |
Filtering | No |
Handles Included | Yes |
Sidespray | No |
Valve Included | Yes |
Characteristics and Features
Faucet Holes | 1 |
Handle Material | Metal |
Handle Style | Lever |
Material | Brass |
Mounting Type | Single Hole |
Number Of Handles | 1 |
Pre Rinse | No |
Pullout Spray | No |
Valve Type | Ceramic Disc |
Characteristics and Features
Faucet Holes | 1 |
Handle Material | Metal |
Handle Style | Lever |
Material | Brass |
Mounting Type | Single Hole |
Number Of Handles | 1 |
Pre Rinse | No |
Pullout Spray | No |
Valve Type | Ceramic Disc |
Warranty and Product Information
ADA | Yes |
Approved for Commercial Use | Yes |
Collection | Commercial |
Country Of Origin | Canada |
Made in America | Yes |
Warranty and Product Information
ADA | Yes |
Approved for Commercial Use | Yes |
Collection | Commercial |
Country Of Origin | Canada |
Made in America | Yes |
