Delta Commercial 81/83T Urinal Flush Valve
Model: 81T231-19|Item: bci2242978
from theCommercial Collection
$149.35
Finish: Chrome -
Special Order
Details
Product Features:
- Quiet action, Teck exposed diaphragm flush valve
- Vandal resistant cover screw
- Metal (non hold open) ADA Compliant oscillating handle
- Vacuum breaker
- Renewable seat
- Chloramine resistant diaphragm attached to guide with forged metal retainer
- Spud flange and concealed spud nut
- For flushing urinals with 3/4" top spud
- Maximum 330mm(13") from centerline of valve inlet to top of urinal
- 1" FIP 3/4" Copper sweat inlet adaptor for angle check stop with protecting cap
- Adjustable 121mm (4.75”) plus or minus 11mm (7/16”) inlet/valve outlet centers
- Cover tube and S/S wall flange
- Factory Set to 1.9L (0.50 Gal.) - not field adjustable
Product Certifications:
- IAPMO listed to CSA B125.3/ ASSE 1037
- ADA compliant to meet Handicapped Accessibility Standard ICC/ANSI A117.1 of less than 5 lbs operating force
Dimensions and Measurements
Gallons Per Flush | 0.5 |
Height | 15.4 in. |
Product Weight | 3.1 lbs. |
Spud Size | .75 in. |
Dimensions and Measurements
Gallons Per Flush | 0.5 |
Height | 15.4 in. |
Product Weight | 3.1 lbs. |
Spud Size | .75 in. |
Included Components
Handles Included | Yes |
Included Components
Handles Included | Yes |
Characteristics and Features
Configuration | Concealed |
Control Type | Manual |
Handle Material | Metal |
Handle Style | Lever |
Installation Type | Urinal |
Material | Brass |
Spud Placement | Top |
Characteristics and Features
Configuration | Concealed |
Control Type | Manual |
Handle Material | Metal |
Handle Style | Lever |
Installation Type | Urinal |
Material | Brass |
Spud Placement | Top |
Warranty and Product Information
ADA | Yes |
Approved for Commercial Use | Yes |
CA Drought Compliant | No |
Collection | Commercial |
Country Of Origin | Canada |
Made in America | Yes |
TX Drought Compliant | Yes |
Warranty and Product Information
ADA | Yes |
Approved for Commercial Use | Yes |
CA Drought Compliant | No |
Collection | Commercial |
Country Of Origin | Canada |
Made in America | Yes |
TX Drought Compliant | Yes |
