Broan Glacier 240 - 300 CFM 36 Inch Wide Under Cabinet Range Hood with LED Lights
Model: BCSEK136WW|Item: bci4555679
Details
Glacier BCSEK1 is an Energy Star qualified under-cabinet convertible range hood that features a clean, contemporary shape to complement nearly any kitchen design. Equipped with the exclusive Broan Captur™ system, which combines advanced blower design with new filter technology, this 300 MAX Blower CFM-rated hood provides 97.4% removal of smoke and odor to protect your home and family from airborne pollutants caused from cooking. The quiet-running Glacier is also designed with smooth flow technology, which streamlines the path of air for improved efficiency and noise reduction. Easy-flip rocker switches control the 2 fan speeds and Energy Star qualified LED lighting system.
Using the included EZ1® system, Glacier can easily be installed by one person in up to half the time of a standard install.
Features:
- Blower outputs up to 300 CFM to keep your kitchen free of cooking fumes and odors
- Mesh filters effectively trap and filter out unwanted smoke, odors, and grease
- Hood is Energy Star certified providing better performance and longer life
- EZ1 brackets make it easy for single person installation in less than half the time of traditional methods
- 2 LED lights illuminate the cooking area
- Complements items from the Glacier collection
- Range hood is installed as hardwired or with an optional power cord kit (SHCK44 sold separately)
- Hood can be converted to ductless ventilation for improved efficiency and flexible installation options
- Rocker controls allow you to easily set the power level of your range hood
- 2 available speeds provide just the right amount of ventilation
- Covered under a 1 year manufacturer warranty and a 3 year LED module manufacturer warranty
Product Technologies:
- Captur™ : Advanced blower design features a forward positioned centric inlet to remove smoke and odor faster
Specifications:
- CFM: 240
- Sones: 1.5
- Nominal Width: 36"
- Width: 23-7/8", 29-7/8", 35-7/8"
- Height: 6"
- Depth: 19-5/8"
- Duct Size: 3-1/4" x 10", 7" Round
- Height Above Cooktop: 18" to 24"
- Frequency: 60 Hz
- Amperage: 0.65A
- Voltage: 120V
- Wattage: 78W
Dimensions and Measurements
CFM | 240, 300 |
Depth | 19.625 in. |
Duct Size | 3-1/4" x 10", 7" Round |
Height | 6 in. |
Height Above Cooktop | 18" to 24" |
Height Above Cooktop (Max) | 24 in. |
Height Above Cooktop (Min) | 18 in. |
Nominal Width | 36 in. |
Width | 23.875, 29.875, 35.875 in. |
Dimensions and Measurements
CFM | 240, 300 |
Depth | 19.625 in. |
Duct Size | 3-1/4" x 10", 7" Round |
Height | 6 in. |
Height Above Cooktop | 18" to 24" |
Height Above Cooktop (Max) | 24 in. |
Height Above Cooktop (Min) | 18 in. |
Nominal Width | 36 in. |
Width | 23.875, 29.875, 35.875 in. |
Included Components
Available Without Blower | No |
Bulb Included | Yes |
Convertible to Ductless / Recirculating | Yes |
Ductless | No |
Includes Remote | No |
Light Included | Yes |
Included Components
Available Without Blower | No |
Bulb Included | Yes |
Convertible to Ductless / Recirculating | Yes |
Ductless | No |
Includes Remote | No |
Light Included | Yes |
Characteristics and Features
Blower Type | Internal |
Bulb Type | LED |
Control Type | Rocker |
Duct Discharge | Horizontal, Vertical |
Filter Type | Mesh Filters |
Installation Type | Full Installation |
Material | Steel |
Number of Bulbs | 2 |
Panel Ready | No |
Characteristics and Features
Blower Type | Internal |
Bulb Type | LED |
Control Type | Rocker |
Duct Discharge | Horizontal, Vertical |
Filter Type | Mesh Filters |
Installation Type | Full Installation |
Material | Steel |
Number of Bulbs | 2 |
Panel Ready | No |
Electrical and Operational Information
Amperage | 0.65 |
Frequency | 60 Hertz |
Sones | 1.5 |
Speeds | 2 |
Voltage | 120 |
Wattage | 78 |
Electrical and Operational Information
Amperage | 0.65 |
Frequency | 60 Hertz |
Sones | 1.5 |
Speeds | 2 |
Voltage | 120 |
Wattage | 78 |
Warranty and Product Information
ADA | No |
Approved for Commercial Use | No |
Certifications | HVI, UL |
Collection | Glacier |
Country Of Origin | Mexico |
Energy Star | Yes |
Manufacturer Warranty | 1 Year, 3 Year LED |
Outdoor Approved | No |
Title 24 | Yes |
Warranty and Product Information
ADA | No |
Approved for Commercial Use | No |
Certifications | HVI, UL |
Collection | Glacier |
Country Of Origin | Mexico |
Energy Star | Yes |
Manufacturer Warranty | 1 Year, 3 Year LED |
Outdoor Approved | No |
Title 24 | Yes |
